| Motherboard |
Super X11SPW-TF
|
| CPU |
Single Socket P (LGA 3647)
2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡
Support CPU TDP 70-205W*
Up to 28 Cores
* Certain high frequency optimized CPU are not supported, such as Intel Gold 6250 and 6256.
‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)
|
| RAM |
6 DIMM slots
Up to 1.5TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM
2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
† 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
†† Cascade Lake only.
|
| Chipset |
Intel® C622 chipset
|
| SATA |
SATA3 (6Gbps); RAID 0, 1, 5, 10
|
| Network Controllers |
Dual 10GBase-T LAN with Intel® X722 + X557
|
| IPMI |
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
|
| Video |
ASPEED AST2500 BMC
|
| Input / Output |
10 SATA3 (6Gbps) ports
2 RJ45 10GBase-T LAN ports
1 RJ45 dedicated IPMI LAN port
5 USB 3.0 ports (2 rear + 2 headers + 1 Type A)
7 USB 2.0 ports (2 rear + 5 headers)
1 VGA port
2 COM ports (1 rear, 1 header)
2 SuperDOM (Disk on Module) ports with built-in power
|
| Drive Bays |
4 Hot-swap 3.5" SATA3 drive bays
|
| System Cooling |
5 Counter-rotation 40x56mm PWM fans
1 fan for AOC cooling (option)
|
| PCI-Express |
2 PCI-E 3.0 x16 (FHFL) slots
1 PCI-E 3.0 x8 (LP) slot
|
| M.2 |
1x M.2 Interface: PCI-E 3.0 x4 and SATA
Form Factor: 2280, 22110
Key: M-Key
Double Height Connector
|
| Drive Bays |
4 Hot-swap 3.5" SATA3 drive bays
|
| Power Supply |
500W Redundant Power Supplies with PMBus
|
| Form Factor |
1U Rackmount
|
| Размеры (Ш х В х Г) |
437mm х 43mm Х 650mm
|
| Вес |
Брутто - 21.77 кг
Нетто - 10.89 kg
|
