| Производитель |
Supermicro
|
| Тип продукции |
Серверная платформа
|
| Модель |
SYS-6029P-WTR
|
| Материнская плата |
Super X11DDW-NT
|
| CPU |
Dual Socket P (LGA 3647)
2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,
Dual UPI up to 10.4GT/s
Support CPU TDP 70-205W
Up to 28 Cores
BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)
|
| RAM |
12 DIMM slots
Up to 3TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
Supports Intel Optane DCPMM
2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
|
| On-Board Devices |
Intel® C621 chipset
SATA3 (6Gbps); RAID 0, 1, 5, 10
Dual 1GbE LAN with Intel C621
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
ASPEED AST2500 BMC
|
| Input / Output |
12 SATA3 (6 Gbps) ports
2 RJ45 GbE ports
1 RJ45 Dedicated IPMI LAN port
4 USB 3.0 ports (rear)
1 VGA port
2 SuperDOM (Disk on Module) ports
|
| Chassis |
CSE-826BAC4-R1K23WB 2U Rackmount
|
| Управление |
Power On/Off button
UID button
|
| Индикация |
Power status LED
HDD activity LED
Network activity LEDs
Universal Information (UID) LED
|
| Backplane |
SAS/SATA HDD Backplane
|
| Охлаждение |
3 High-performance 8cm PWM fans
|
| PCI-Express |
4 PCI-E 3.0 x8 (FHHL) slots
2 PCI-E 3.0 x8 (LP) slots
1 PCI-E 3.0 x16 for Add-on-Module (AOM)
1 PCI-E 3.0 x4 NVMe M.2 slot
(необходима установка 2xCPU)
|
| Дисковые отсеки |
8x Hot-swap 3.5" SAS/SATA drive bays with SGPIO
2x Fixed 3.5" drive bays
|
| БП |
2x1000W Redundant Power Supplies with PMBus
|
| Размеры |
437x89x648mm
|
| Вес, кг |
28.1 kg
|
